Access Point AIR-AP1852I-A-K9 Cisco m1 Aironet 1852I Wireless 802.11ac Dual *** NUEVO
$0 iva incluido
AIR-AP1852I-A-K9 es uno de los puntos de acceso de la serie Cisco Aironet 1850. La serie 1850 AP de Cisco es ideal para redes pequeñas y medianas. Esta serie es compatible con puntos de acceso MIMO 4×4 de clase empresarial y de cuatro flujos espaciales que admiten la nueva especificación 802.11ac Wave 2 del IEEE. La serie 1850 amplía la compatibilidad con una nueva generación de clientes Wi-Fi, como teléfonos inteligentes, tabletas y ordenadores portátiles de alto rendimiento que llevan integrada la compatibilidad con 802.11ac Wave 2. El modelo AIR-AP1852I-A-K9 proporciona un dominio regulador A y antenas internas.
Sin existencias
Descripción
AIR-AP1852I-A-K9 Overview
AIR-AP1852I-A-K9 is one of the Cisco Aironet 1850 Series Access Points. Cisco 1850 AP series is ideal for small and medium-sized networks. This series supports enterprise-class 4×4 MIMO, four-spatial-stream access points that support the IEEE’s new 802.11ac Wave 2 specification. The 1850 Series extends support to a new generation of Wi-Fi clients, such as smartphones, tablets, and high-performance laptops that have integrated 802.11ac Wave 2 support. The model AIR-AP1852I-A-K9 provides A Regulatory Domain and internal antennas.
Quick Specs
Table 1 shows the quick specs of AIR-AP1852I-A-K9.
| Part Number | AIR-AP1852I-A-K9 |
| Description | 802.11ac Wave 2 Access Point, 4×4:4, Internal-Ant, A Regulatory Domain |
| Features | – 4×4 MIMO with four spatial streams, single-user MIMO
– 4×4 MIMO with three spatial streams, multiuser MIMO – MRC – 802.11ac beamforming (transmit beamforming) – 20-, 40-, and 80-MHz channels – PHY data rates up to 1.7 Gbps (80 MHz in 5 GHz) – Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx) – 802.11 DFS – CSD support |
| Regulatory Domain | A (A regulatory domain):
– 2.412 to 2.462 GHz; 3 channels – 5.180 to 5.320 GHz; 8 channels – 5.500 to 5.700 GHz; 8 channels (excludes 5.600 to 5.640 GHz) – 5.745 to 5.825 GHz; 5 channels |
| Antenna | Internal Antenna |
| Interfaces | – 1 x 10/100/1000BASE-T autosensing (RJ-45), Power over Ethernet (PoE)
– 1 x 10/100/1000BASE-T autosensing (RJ-45), AUX (used for Link Aggregation) – Management console port (RJ-45) – USB 2.0 (enabled via future software) |
| Dimensions (W x L x H) | 8.3 x 8.3 x 2 in. (210.8 x 210.8 x 50.8 mm) |
| Weight | 3.12 lb (1.41 kg) |
Product Details
Figure 1 shows the AIR-AP1852I LED Indicator Position.
Note: ① LED indicator position
Table 2 shows the AP LED indicators’ descriptions.
| Message Type | LED State | Message Meaning |
| Association status | Chirping Green | Normal operating condition, but no wireless client associated |
| Green | Normal operating condition, at least one wireless client association | |
| Boot loader status | Green | Executing boot loader |
| Boot loader error | Red | Boot loader signing verification failure |
| Access point
regulatory domain priming status |
Blinking Amber | AP priming to a new regulatory domain by Neighbor Discovery Protocol (NDP), in progress |
| Cycling Red, Green and off | AP waiting to be primed | |
| Chirping Red | AP primed to a wrong regulatory domain | |
| Operating status | Blinking amber | Software upgrade in progress |
| Cycling through green, red, and amber | Discovery/join process in progress | |
| Rapidly cycling through red, green, amber, and off. | Access point location command invoked from controller web interface. | |
| Access point operating
system errors |
Cycling through red, green, amber, and off | General warning; insufficient inline power |
Figure 2 shows AIR-AP1852I Ports and Connections.
Note:
| ① | Mode button | ④ | AUX (Auxiliary) port. |
| ② | RJ-45 console port | ⑤ | PoE-In port (Ethernet Uplink port) |
| ③ | USB 2.0 port | ⑥ | 48 V DC input power port |
